Precision Profile Extrusion Line

Description:

This extrusion line is the series which can manufacture PVC, PP, PE, PS, PC, ABS, PMMA profile products to fulfill market need, it adapts to different characteristics of different materials meanwhile take production efficiency into consideration.

BAOD EXTURSION Precision profile extrusion line covers single-screw extruders, twin-screw extruders, different kinds of dies and all downstream components, supplied either separately or as complete extrusion lines with any level of automation. All our components and automation systems are engineered to maximize savings on materials, energy and costs, without compromising on product quality. We are your expert partner for any type of profile extrusion line.


Product Detail

Product Tags

Features

- Equipped with BAOD EXTRUSION single or twin screw extruder, it can fulfill the need of processing PVC, PP, PE, PS, PC, ABS, PMMA et cetera;
- Optimized designed tooling, precise fabricated, high quality material; Match with double/multi position puller and cutter, can realize dual or multi strand extrusion by one die;
- 3-Dimension adjustable vacuum calibrating unit, optimized vacuum switch, flow switch, multiple choices of dies.
- Dynamic balance type caterpillar haul-off, frequency conversion/DC speeding, stable running , convenient operation;
- Cutter adopts professional designed saw blade, controlled by PLC, smooth flat cut;
- Optimized length counter and dust collector configuration.

najsn
nnasc
jigodasgd

Our advantage

Main Technical Parameter

Model:

YF80

YF120

YF180

YF240

YF300

YF400

YF600

Max. Product Width (mm):

80

120

180

240

300

400

500

Installation Power (kW):

9.5

13

19.5

27.5

31.6

31.6

37.1

Cooling Water Flow (m²/h):

4

5

6

7

8

9

11
